DH-IPC-HDW3549HP-AS-PV - Dahua 5MP TiOC Turret Camera

The Dahua TiOC Turret Camera is the best of the Dahua range in one camera. The TiOC is able to identify people and vehicles while ignoring other debris that may be causing false alarms. With an image sensor that gives you full colour 24/7 as well as active deterrence, it truely is an all in one camera.
Shop Dahua Packages

Features

  • 5MP, 1/2.7” CMOS image sensor, low illuminance, high image definition
  • H.265 codec, high compression rate, low bit rate
  • Built-in warm illuminator, and the max. illumination distance: 30 m
  • ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments
  • Intelligent detection: Intrusion, tripwire
  • Supports one-tap disarming. You can disarm the events of alarm output, sending email, audio, and light in the configured period
  • 12V DC/PoE power supply
  • IP67 protection
  • SMD Plus
  • Red and blue flashlight alarm
Spec Sheet Quick Start Guide

  • Video Compression: H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream)
  • Smart Codec: Smart H.265+/Smart H.264+
  • Video Frame Rate: Main stream: 2592 × 1944 @1-20 fps 2688 × 1520 @1-25/30 fps, Sub stream: 704 × 576 @1-25 fps/704 × 480 @ 1-20fps, Third stream: 1920 × 1080 @1-25/30 fps
  • Stream Capability: 3 streams
  • Resolution: 5M (2592 × 1944); 4M (2688 × 1520); 4M (2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (354 × 288/354 × 240)
  • Bit Rate Control: CBR/VBR
  • Video Bit Rate: H.264: 32 kbps–8192 kbps H.265: 12 kbps–8192 kbps
  • Day/Night: Color/B/W
  • BLC: Yes
  • HLC: Yes
  • WDR: 120 dB
  • Scene Self-adaptation: Yes
  • White Balance: Auto/natural/street lamp/outdoor/manual/regional custom
  • Gain Control: Auto/Manual
  • Noise Reduction: 3D DNR
  • Motion Detection: OFF/ON (4 areas)
  • Region of Interest (RoI): Yes (4 areas)
  • Smart Illumination: Yes
  • Image Rotation: 0°/90°/180°/270° (Support with 1080p resolution and lower)
  • Mirror: Yes
  • Privacy Masking: 4 areas

  • Image Sensor: 1/2.7”5Megapixel progressive CMOS
  • Max. Resolution: 2592 (H) × 1944 (V)
  • ROM: 128 MB
  • RAM: 512 MB
  • Scanning System: Progressive
  • Electronic Shutter Speed: Auto/Manual 1/3 s–1/100,000 s
  • White Balance
  • Min. Illumination: 0.003 Lux @ F1.0
  • S/N Ratio: >56 dB
  • Illumination Distance: 30 m (98.4 ft)
  • Illuminator On/Off Control: Auto/Manual
  • Illuminator Number: 1 (Warm light)
  • Pan/Tilt/Rotation Range: Pan: 0°–360° Tilt: 0°–78° Rotation: 0°–360°

  • Lens Type: Fixed-focal
  • Mount Type: M12
  • Focal Length: 2.8 mm; 3.6 mm
  • Max. Aperture: F1.0
  • Field of View: 2.8 mm: Horizontal 103° × Vertical 53° × Diagonal 122° 3.6 mm: Horizontal 81° × Vertical 43° × Diagonal 95°
  • Iris Type: Fixed
  • Close Focus Distance: 2.8 mm: 1.2 m (3.9 ft) 3.6 mm: 2.1 m (6.9 ft)

  • Network: RJ-45 (10/100 Base-T)
  • SDK and API: Yes
  • Protocol: IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; 802.1x; SNMP
  • Interoperability: ONVIF (Profile S/Profile G/Profile T); CGI; Milestone; Genetec; P2P
  • User/Host: 20 (Total bandwidth: 80 M)
  • Storage: FTP; SFTP; Micro SD card (support max. 256 G); Dahua Colud; NAS
  • Browser: IE: IE8 and later, Chrome, Firefox, Safari: Safari 12 and later
  • Management Software: Smart PSS; DSS; DMSS
  • Mobile Phone: IOS; Android

  • Environment Noise Filtering: Yes
  • Audio Sampling Rate: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
  • Audio Compression: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3
  • Audio Bit Rate: 64Kbps(G.711ulaw/G.711alaw)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/8-320Kbps(MP3)

  • IR Range: Up to 30 m
  • Wavelength: 850 nm
  • Smart Supplement Light: Yes
  • Visual Alarm: Yes

  • Day/Night Switch: Day, Night, Auto, Schedule
  • Image Enhancement: BLC, HLC, 3D DNR
  • Image Parameters Switch: Yes
  • Image Settings: Saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser

  • EMC: FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015)
  • Safety: UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014 ); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014 ); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015); LOA (IEC/EN 60950-1)
  • Environment: CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
  • Protection: Ingression protection: IP66 (IEC 60529-2013)

  • Alarm: 1 input, 1 output (max. 12 VDC, 30 mA)
  • Audio: 1 input (line in), terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium; 1 output (line out), terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium; 1 built-in speaker, 1 built-in microphone
  • On-Board Storage: Built-in micro SD/SDHC/SDXC slot, up to 256 GB
  • Hardware Reset: Yes
  • Communication Interface: 1 RJ45 10M/100M self-adaptive Ethernet port

  • Linkage Method: Upload to NAS/memory card, notify surveillance center, trigger record, trigger capture, strobe light, audible warning *Note: External device is required.
  • Web Client Language: 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
  • General Function: Anti-flicker, heartbeat, mirror, privacy masks, flash log, password reset via e-mail, pixel counter
  • Software Reset: Yes
  • Storage Conditions: -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
  • Startup And Operating Conditions
  • -30 °C to 60 °C (-22 °F to 140 °F)
  • Power Supply: 12 VDC ± 25%, reverse polarity protection; PoE: 802.3af, Class 3
  • Power Consumption And Current: 12 VDC, 0.75 A, max. 9 W PoE: (802.3af, 36 V to 57 V), 0.28 A to 0.17 A, max. 10 W
  • Power Interface: Ø5.5 mm coaxial power plug
  • Material: Metal except for trim ring
  • Camera Dimension: Ø138.3 × 124.5 mm (Ø5.4" × 4.9")
  • Package Dimension: 170 × 170 × 150 mm (6.9" × 6.9" × 5.9")
  • Camera Weight: Approx. 800 g (1.8 lb.)
  • With Package Weight: Approx. 1093 g (2.4 lb.)

  • Face Capture: Yes
  • Premier Protection: Line crossing detection, intrusion detection, region entrance detection, region exiting detection

  • Basic Event: Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error), scene change detection
